E-Glass Plain280GSM 84215 Fiberglass bulked fabric for filter has an advantages of a high temperature, corrosion resistance, dimensional stability, minimal shrinkage, elongation, high strength, filtering speed, sound absorption, shock absorption, insulation, flame resistance, folding resistance and so on.
Characteristics:
1.Corrosion resistant, high strength, fireproofing, heat preservation, electrical insulation properties etc.
2.Don't need treatment, good soak, bonding with different of matrix resin.
3.Fiberglass cloth has good mechanical strength.
4.Good base cloth, you can coated silicone, aluminium foil, TEPT etc in it.
Application:
Insulation industry, oil pipe packing, duck work, building materials industry, shipbulding industry, composite material, good base cloth etc
It is widely used in iron and steel industry.
This cloth is for thermal insulation, insulation and the coating.
Techncial Data Sheet:
| Data sheet for Fiberglass Bulked Fabrics |
| Type | Weave | Warp | Weft | Width
(cm) | Density
(ends/cm) | Area weight
(g/m2) | Thickness
(mm) |
| 84215 | Plain | ET6-204 T215 | ET6-204 T215 | 100-220 | 8x6 | 280 | 0.38 |
| 2025 | Plain | ET6-408 T430 | ET6-408 T430 | 100-220 | 8x6 | 600 | 0.75 |
| 2626 | Twill | ET9-544 T580 | ET9-544 T580 | 100-220 | 10X6 | 950 | 1.00 |
| M24 | Plain | ET9-816 T860 | ET9-816 T860 | 100-220 | 6X3.8 | 816 | 1.00 |
| M30 | Plain | ET9-816 T860 | ET9-1244 T1250 | 100-220 | 6X4 | 1020 | 1.40 |
| M35 | Plain | ET9-816 T860 | ET9-1768 T1800 | 100-220 | 6X3.8 | 1190 | 1.50 |
| M52 | Plain Panama | ET9-816 T860 | ET9-952 T1290 | 100-220 | 6X2/2.5X2 | 1780 | 3.00 |
| M35(G) | Plain Panama | ET9--612 T625(G) | ET9--612 T625(G) | 100-220 | 6X2/3.4X2 | 1200 | 1.50 |
| EWTF750 | Satin Double Weft | EC6-68 1/2 | ET6-272 T280 | 100-220 | 18X16 | 750 | 0.75 |
| Other models can be customized. |
| | | | | | | | |
| CHANGZHOU UTEK COMPOSITE COMPANY CO.,LTD |
|
| COMPANY INTRODUCTION: |
| Company Name | CHANGZHOU UTEK COMPOSITE CO.,LTD |
| Address | Fuhanyuan 1-814,Taihu Road,Changzhou,Jiangsu,China |
| Contact Person | Name | Tel |
| Manger | Gong Xiaojun | 0086 13357899376 |
| Manger | Irene Xi | 0086 13961156380 |
| Business Condition | Manufacture | Trading |
| Consititution of company | Pvt.Ltd |
| Annual turnover | USD10,000,000 |
| Company Occupy Areas(M2) | 3000M2 |
| Shower room Occupy Areas(M2) | 200M2 |
| website | www.utekcomposite.com |
| http://utekcomposites.en.made-in-china.com/ |
| Mainly Customer & Marketing | Europe,Asia,America,Middle East |
| Mainly Product | Fiberglass chopped strand mat (powder and emulsion), stitch mat, combo mat, uni-direction and biaxial fabric, RTM core mat, woven roving, special products like Ar-glass roving, chopped strand, thin fiberglass fabric, SMC(sheet molding compound), fiberglass/polyester geogrid and geocomposite. fiberglass mica fabric for insulation. |
|
|
|
| Sales Team | 15(University Graduates) | Product Team |
| Research & Development Team | 12 | QC Team |
| Certificate | ISO 9001 ,ISO 14001 ,SGS |
Give us a chance, and we' ll return you with satisfaction.
Changzhou Utek Composite Co. Is committed to provide tailor-made service to customers with various requirements. We pay attention to needs of customers who adopt different production technologies like hand lay up, pultrusion, winding, close molding… Changzhou Utek is customer-oriented, from sales to production, in each step.
With many years of experiences in composite industry, we utilize our good working knowledge to develop, manufacture and distribute materials for:
Composite Reinforcement
1. Fiberglass cloth for surfboard: Standard and warp enhanced, have a lot of export to Australia, Indonesia, Brazil, Argentina…
2. Sandwich mat with PP core for RTM process: Exported to Russia, Malaysia, Spain, used to make big size road plate, cooling tower…
3. Fiberglass chopped strand mat: Big roll and wide width available, good quality of light weight mat for auto headliner such as 100g, 120g, 150g
4. Other reinforcement material such as stitch mat, combo mat, uni-direction and biaxial fabric, woven roving, Ar-glass roving, chopped strand
Chemicals:
1. SMC/BMC: Experienced in SMC for water tank, electric meter box, manhole cover. Have a lot of export to Saudi Arabia, South Africa, Malaysia
2. UP resin: Exported to Thailand, Chile, Nigeria
GRC: Ar-glass spray up roving, Ar-glass chopped strand, exported to Saudi Arabia, Egypt, Indonesia…
Geosynthetics: Fiberglass/polyester geogrid, paving grid, drainage geonet for landfill
We' Re one step source for composite reinforcements. Give us a chance, and we' Ll return you with satisfaction.
