Features:
Various levers and terminals are available for choice.
Various operating force are available.
Snap action, compact design, suit for small space.
Long operating life, high reliability, which could save the cost.
Various rating and temperature resistance degree are available.
CCC,CE,UL,VDE approvals.
Application:
Home appliance,Electronic device,Automation equipment,Communication equipment,Auto electronic, Instrument and meter,Sprayer machine,Water pump, Game machine, Air conditioner, Electric tool etc.
2.Specification
| Item | Date |
| Operation speed |
| 0.1mm-1m/s |
| Operation frequency | Mechanical | 600time/min |
| Electrical | 40time/min |
| Insulation resistance |
| 100MΩ(above)(DC500V) |
| Contact resistance |
| 25MΩ initial value |
| Withstand voltage | Non-connection wire | 1500VAC |
| Every terminal | 2000VAC |
| Vibration | Misoperation | 10-55Hz(Amplitude)1.5mm |
| Impact | Durable | 1000m/s |
| Misoperation | 300m/s |
| Life | Electrical | 10,000(above) |
| Mechanical | 1,000,000(above) |
| Pretection degree |
| IP40 |
| Ambient operating temperature |
| "-25+80ºC |
| Humidity |
| <=82% |
| Ue(v) | Le(A) | 1th(A) |
| AC-250 | 7.5 | 10 |
| AC-125 | 15 | 20 |
| DC-250 | 0.3 | 0.45 |
| DC-125 | 0.6 | 0.75 |
3.Operating Characteristics
| Operation speciality | V-21-1-6 | V-16-1-5 |
|
| OF | 130g | 65g |
| RF | 12g | 6g |
| PT | 9.0mm |
| OT | 2.0mm |
| MD | 2.8mm(0.8mm) |
| OP | 15.2±3.2mm |
4.Why choose our switches
1) We can provide you with different types of micro switches for your selection.
2) We can offer good quality electric life 500, 000-1, 000, 000times.
3) Various operating force, height and color for one switch for your choice.
4) Safety, on-time delivery, excellent quality with competitive price.
5) ODM&OEM professional design.
5.Customer's questions
Q1:How about the delivery time?
Answer:It's depends on the quantity, for example, 10000PCS need to OEM,
delivery time is 3-7 days.
Q2:What quality you can offer to us?
Answer:We now can do 1/2 years warranty, during the warranty time we can exchange all defective products from customers for free.
Q3:Can you give me samples to test?
Answer:Yes
Q4:What's you MOQ?
Answer:MOQ 2500PCS, mixed order acceptable, welcome trial order.
6.More information of our products, please do feel free to contact us.
Reply will be available within 24 hours. Thanks!
Yueqing Nanma Electrical Co., Ltd.and Jiangxi Nanma Electrical Co, Ltd Which a professional R&D and manufacture Micro switch, limit switch, travel swith, sealed switch, waterproof switch, toggle switches and so on Our company was established in 2004. Our ISO 9001-certified factory occupy a total land area of 1000 square meters and house more than 200 employees and two production lines outfitted with advanced production equipment. We have a monthly outup of 10 thousand sets of switch, which are exported to the Southeast Asia, Middle East, European. The market feedback shows that the products may completely substitude for the similar, work force: Our 2 QC auditors ensure all our products passed CE and CCC certifications. Implementing strict quality control in the whole production process, We have 2 R&D personnel with more than five years of experience who can design as customer offered sample to open model. We have 4 trade representatives with more than three years of experoence who are proficient in English. We are sincerely invite you to witness our development and resplendence together! Contact us today.
