Waterproof IP68 16 Outdoor LED Curtain Mesh
| Price: |
US $ 100-2000/Square Meter |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T |
Wind-Proof LED Curtain for Huge Projects
1. 80% Transparency.
2. Brightness: > 6500 nits.
3. Easy Front Service without tools.
4. Light: 10-15kg/m²
Contact Us Now to know more: mobile: +86 13538127671
| LED Curtain Datasheet |
| Features | High Density, Large Viewing Angle, High Performance, High-end Curtain |
| Model | CXG 25 | CXG 14 | CXG 7 |
| LED Lamp | SMD3535 | SMD3535 | SMD3535 |
| Pixel Pitch (H)(mm) | 25 | 25 | 12.5 |
| Pixel Pitch (V)(mm) | 15.625 | 7.8125 | 7.8125 |
| Pixel Density (dot/) | 2560 | 5120 | 10240 |
| Grey Scale (bit) | 16 | 16 | 16 |
| Brightness (cd/) | ≥5500cd | ≥6000cd | ≥6500cd |
| Brightness Adjustment (unhurting grey scale) | 5%~100% | 5%~100% | 5%~100% |
| Viewing Angle(H/V) | 110° / 110° | 110° / 110° | 110° / 110° |
| Best Viewing Distance(m) | 15-300 | 8-160 | 8-160 |
| Power Consumption(W/) | Max:480; Average:144 | Max:480; Average:144 | Max:480; Average:144 |
| Weight (kg/ | 13 | 13 | 16 |
| Thickness (mm) | 13-58 | 13-58 | 13-58 |
| Installation Thickness(mm) | 118 | 118 | 118 |
| Refresh Rate (Hz) | 2380 | 2380 | 2380 |
| Data Interface | DVI/HDMI | DVI/HDMI | DVI/HDMI |
| Control Method | Synchronized with computer monitor | Synchronized with computer monitor | Synchronized with computer monitor |
| Drving Mode | Static constant driving | Static constant driving | Static constant driving |
| Display Mode | 1920*1080 | 1920*1080 | 1920*1080 |
| LEDs Lifetime | >100,000 | >100,000 | >100,000 |
| Transparency Rate (%) | 70.00% | 70.00% | 40.00% |
| Waterproof | Front / Back IP68 | Front / Back IP68 | Front / Back IP68 |
| Noice Level (db) | 0 | 0 | 0 |
| Control System | Integreated Control inside | Integreated Control inside | Integreated Control inside |
| Way of Installation | Tool-free fast installation | Tool-free fast installation | Tool-free fast installation |
| Fire Safety | 5S /unit, Tool-free uninstall | 5S /unit, Tool-free uninstall | 5S /unit, Tool-free uninstall |
| Maintainence Speed | 10S/unit | 10S/unit | 10S/unit |
| Maintainence Mode | Front / Back | Front / Back | Front / Back |
Why Chengxinguang(CXG) LED Display1. Competitive Price
We are middle-sized Chinese local factory, maybe you can see that from our so Chinese name of "Chengxinguang", unlike the internationalized name of foreign trade company. Besides, we control our cost very well and don't have huge management cost like top companies, so that we can give the real benefits to our customers.
2. Close Relationships with Raw Material Providers
For our bosses have been in the key positions at the top led display factory since 2004, we have very close and strategic relationship with the raw material providers, which support the stable quality of our products.
3. Quality Control
From raw materials to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability.
| Prod Model: |
P16 |
| Maintainence Speed: |
10s/Unit |
| Factory: |
OEM, ODM |
| Maintainence Mode: |
Front / Back |
| Warranty: |
2 Years |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
25mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
180W / m² |
| Scanning Mode: |
Static Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
CCC |
| Pixel Density: |
2560 Dots / Sqm, 5120 Dots / Sqm, 10240 Dots / Sqm |
