Gold Wear-resistance Cold Work Mould Steel Plate (1.2080/SKD1/D3)
1, Application:
Used for making small impact, high quality wear cold-punching mould;
1) Used for high tolerance and long service life of all kinds of cold stamping die and cold shear blade, thread rolling plate, etc.;
2) Tabletting punches and sleeves for corrosive;
3) Suitable for complex deformation of mould;
2, Features:
1) High hardenability, high hardness, high wear resistance and good toughness, quenching deformation, etc;
2) High carbon high chromium tool steel;
3) Good machinablity and inoxidizability;
4) Immune from sinking in use, high resistance to heavy pressure;
3, Steel Grade: 1.2080/ D3/ SKD1/Cr12 Cold Work Mould Steel
4, Specification:
| Chemical Compositons |
| Grade | C | Si | Mn | P | S | Cr | W | V |
| Cr12 | 2.00-2.30 | ≤0.40 | ≤0.40 | ≤0.030 | ≤0.035 | 11.50-13.0 | - | - |
| D3 | 2.00-2.30 | 0.10-0.60 | 0.10-0.60 | ≤0.030 | ≤0.030 | 11.00-13.50 | ≤1.00 | ≤1.00 |
| 1.2080 | 1.90-2.20 | 0.10-0.60 | 0.20-0.60 | ≤0.030 | ≤0.030 | 11.00-13.50 | - | - |
| SKD1 | 1.90-2.20 | 0.10-0.60 | 0.20-0.60 | ≤0.030 | ≤0.030 | 11.00-13.50 | - | - |
5, Delivery condition:
Surface: Grinding surface, black surface, turned surface and milling surface according to customer's requirements.
For abundant stock, 15-20 days.
For customized products, 30-50 days.
Package: We provide standard export packing or according to customers' request.
| 6, | Our service |
| 1) | Sizes, materials and others are all at your requirements and can be changed. |
| 2) | Price varies on materials, dimensions, finish craft and different payments. |
| 3) | We are direct manufacture in machinery manufacturing work with experience of several decades. |
| 4) | Detail production design will be made according to information you offered. |
| 5) | We have adequate inventory, so that we can quick delivery. |
| 6) | The most important is that we have advance equipments. |
