computerized children pantyhose knitting machine
Model ID WH-6F-C3
Cylinder Diameter: 4.5 inch
Needle range: 84-240N
Running speed: 280rpm
Power required:
Drive motor: 0.85KW
Fan motor: 0.75KW
Control Box: 0.80KW
Floor space in cm: (W*L*H) 150*120*240
Net weight: 300kg
Gross weight: 350kg
Packing demension in cm: 113*75*157
Function introduction
1. One feeder into yarn
2. Elastic shuttle (can buy two), can knit different colors
3. Each line can knit 6 colors, and there are 13 colors exchanged in the socks pattern.
4. It can knit high heel, big heel, small heel, left and right foot, 180 degree against sock mouth, two colors for sock heads and sock heel.
5. It can knit the three-dimensional socks
6. Back-up battery to protect stored program
7. Internal UPS can support continuous knitting
8. Adopt the double shovel-needle technology. When knitting the heel and toe, the angle is adjusted by computer. In this way, can improve the efficiency and overcome the shortcoming of single shovel-needle.
9. Maximum horizontal stroke pulls can be 45cm
Zhejiang Weihuan Machinery Co., Ltd, which is located in West Industrial Zone, which is near to the "international socks hometown", DaTang town. It is a
Modern enterprise profiessioal in research and development, the assembly, the service one continuous line of manufacture sock machines.
The company, established in 1999, is one of the earliest manfacturers of sock knitting machines. Our company has strong technical force in researching, developing and manufacturing sock machines, accumulated
Rich experience and possessed a Number of machng and testing devices. The companyhas taken the lead in the successful development of WH-600FR domestic production of international standard WH-600FR computerized plane and terry combination, which has come up to international standard. Operating under the scientific management, depending the excellent mechanical performance of our products, and being accepted by our customers, our products have become the most stable type in the conterparts, have been completely able to replace the similae importedproducts. We have good market share in domestic market and also ecported to the Middle East and Southeast Asia and other countries.
The company has been insisting on the principles of " Quality first, Service supreme". We warmly welcome customers at home and abroad to our company for guide and business talk. We sincerely hope to offer the high quality products and good services to our friends from all other the world.
