| Prod Model: |
FFB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| After-Sales Service Provided: |
Engineers Available to Service Machinery Overseas |
| Condition: |
New Automatic Sewing Thread Shrink Packing Machine |
| Material: |
Carbon Steel, 304 Stainless Steel |
| Warranty: |
1 Year |
| Useful Life: |
Over 10 Years |
| Application: |
Medical |
| Packaging Materials: |
Film |
Product Description
Pillow type sewing thread shrink packing/ packaging machine
Application:
Shrink Packaging Machine(FFB) is suitable for packing sewing thread, bottles, cup, instant noodles, food box, batteries, soap, bowls or barrels of convenience food, fruit, milk, milk tea, fine dried noodle, slice buns, disposable tableware, several yogurt cup, toothpaste, cosmetics, mosquito-repellent incense, and outer heat shrinkable packaging.
1.24years experience
2.Touch screen&PLC control
3.Based on Japan technology
4.CE Certificated
Specifications:
1. PLC controller, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and saving films.
2. Human-machine touch screen, Chinese or English displaying, convenient and quick parameter setting.
3. Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
Parameter:
Model |
FFB4599 |
FFB4512 |
FFB4515 |
FFB4518 |
FFB5912 |
FFB5915 |
FFB5918 |
FFB5921 |
Max Film Width (mm) | 450 | 450 | 450 | 450 | 590 | 590 | 590 | 590 |
| Speed(Bag/min) | 30-220 | 30-220 | 30-220 | 30-220 | 30-220 | 30-220 | 30-220 | 30-220 |
| Length of pack (mm) | 70-450 | 70-450 | 90-450 | 100-450 | 80-450 | 90-450 | 100-450 | 100-450 |
| Pack Width (mm) | 10-150 | 10-150 | 10-150 | 10-150 | 10-200 | 10-200 | 10-200 | 10-200 |
| Pack Height(mm) | 5-45 | 5-65 | 5-85 | 5-120 1 | 5-65 | 5-85 | 15-120 | 15-140 |
| Electric Power Voltage(v) | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
| Total Installed Power(kw) | 3.5 | 3.6 | 3.6 | 3.6 | 4 | 4 | 4 | 4 |
| Mass | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000
|
Our Service:
1. Guaranty: One Year
2. One set of tool kits will be provided with the machine.
3. Before delivery, we will adjust the machine to fit for your product.
4. Any question, you can mail/call us at any time. And our most experienced engineers are assigned to give consulting service, and always available for dispatching abroad.
5.Manual is in English.
